Dataforge is a Doh.js module providing a powerful system for defining and executing data manipulation pipelines using chained commands. It features synchronous (Dataforge) and asynchronous (AsyncDataforge) execution contexts, branching, data conversion, and various transformation utilities.

This module bundles several sub-modules:

• dataforge_core: The essential commands and patterns.
• YAML_dataforge: Adds YAML conversion commands.
• nodejs_fs_dataforge: Adds file system commands (Node.js only).
• db_dataforge: Adds sqlite3 through better-sqlite3 for Node, bun:sqlite for Bun, and Alasql for Browser.

This guide covers:

• Installation
• Core Concepts (Dataforge vs AsyncDataforge, Branching, Modes)
• Core Commands
• Branching & Control Flow Commands
• Data Conversion Commands
• Handlebars Templating Commands
• Data Manipulation Commands (Meld, Each)
• String Operation Commands
• Number Operation Commands
• Sanitization & Escaping Commands
• Asynchronous Commands (AsyncDataforge only)
• YAML Commands
• File System Commands (Node.js only)

Installation

Install the module using the Doh.js CLI:

doh install dataforge

This installs the dataforge module and its core dependencies. Specific features might require additional Node.js dependencies (like js-yaml or database drivers) which are typically handled by Doh.js installation processes for those sub-modules.

Core Concepts

Dataforge vs AsyncDataforge Patterns

Dataforge operations are executed using instances of either the Dataforge or AsyncDataforge patterns.

• Dataforge (Synchronous):

  • Executes commands synchronously.
  • Cannot handle overlapping forge() calls on the same instance (will error).
  • Suitable for simple, linear data transformations.

  // Requires 'dataforge' module
  Doh.Module('my_module', ['dataforge'], function() {
      let df = New('Dataforge');
      let result = df.forge('initial data', [
          { Append: ' - transformed' }
      ]);
      console.log(result); // Output: 'initial data - transformed'
  });


• AsyncDataforge (Asynchronous):

  • Executes commands asynchronously, returning a Promise from forge().
  • Includes asynchronous commands (like Fetch, Post).
  • Uses an internal queue: Overlapping forge() calls on the same instance are queued and executed sequentially, preventing race conditions for operations relying on shared state within that instance (like local branches or sequential processing).
  • Suitable for pipelines involving I/O, API calls, or complex sequences.
  • Parallelism: To achieve true parallel execution (e.g., multiple simultaneous API calls), use separate AsyncDataforge instances for each parallel task.

  // Requires 'dataforge' module
  Doh.Module('my_module', ['dataforge'], async function() {
      let adf = New('AsyncDataforge');
      let result = await adf.forge('initial data', [
          { Append: ' - asynchronously transformed' }
      ]);
      console.log(result); // Output: 'initial data - asynchronously transformed'
  });


Branching (Execution Contexts)

Dataforge uses branches to manage data contexts. Each branch holds its own data register and mode settings.

• main branch: The default starting and returning branch.
• Local Branches:
  • Created using the Branch command.
  • Scoped to a single forge() execution. They are cleared when the forge() call completes.
  • Useful for temporary calculations or sub-pipelines.
• Global Branches:
  • Created or accessed using the Global command.
  • Persist across all forge() calls on all Dataforge instances (synchronous and asynchronous).
  • Useful for sharing state between different pipeline executions, but require careful management to avoid race conditions, especially with parallel AsyncDataforge instances.
• Anonymous Branches: If no name is provided to Branch or Global, an anonymous branch (e.g., anon0, anon1) is created.

Modes (Replace, Append, Prepend)

The mode determines how the result of a command updates the data in the current branch.

• Replace (Default): The command's result overwrites the branch's current data.
• Append: The command's result is appended to the branch's data (string concatenation, array concat, object merge).
• Prepend: The command's result is prepended to the branch's data.

Modes can be set persistently using Mode or temporarily for the next command using Replace, Append, or Prepend.

Command Syntax

Commands are passed as an array to the forge() method.

• String: Represents a command with no arguments: "CommandName"
• Object: Represents a command with arguments: { "CommandName": argOrArgs }
  • argOrArgs can be a single value or an array of values.

Core Commands

Import

Replaces the current branch data with the provided argument. Respects the current mode.

// Default mode (Replace)
df.forge('old data', [{Import: "new data"}]); // Result: "new data"

// Append mode
df.forge('old data', ["Append", {Import: " new data"}]); // Result: "old data new data"

Alias: ImportFromValue

ConsoleLog

Logs the current branch data (if no arguments) or the provided arguments to the console.

df.forge('data to log', [
    "ConsoleLog", // Logs: 'data to log'
    { ConsoleLog: "Custom message" } // Logs: "Custom message"
]);

Empty

Sets the current branch data to an empty string ''.

df.forge('some data', ["Empty"]); // Result: ''

Debugger

Triggers the browser/Node.js debugger statement, pausing execution if developer tools are open.

df.forge('data', ["Debugger"]); // Pauses here

Branching & Control Flow Commands

Mode

Sets the persistent mode (Replace, Append, Prepend) for the current branch.

df.forge('data', [
    { Mode: "Append" },
    { Import: " more" } // Appends
    // Mode remains Append for subsequent commands in this branch
]);

Replace, Append, Prepend (Temporary Mode)

Sets the mode for the next command only. Can optionally take data as an argument to perform an immediate Import with that temporary mode.

// Set temp mode for next command
df.forge('data', ["Append", { Import: " next" }]); // Result: "data next"

// Import immediately with temp mode
df.forge('data', [{ Append: " immediate" }]); // Result: "data immediate"

Branch

Executes a sub-pipeline (array of commands) in a specified or anonymous local branch. The current branch data is implicitly copied to the new branch on initialization.

df.forge('main data', [
    { Branch: ['subBranch', [
        // Now in 'subBranch', data is 'main data'
        { Append: ' - modified' },
        "Return" // Returns 'main data - modified' to main branch
    ]]}
    // Back in 'main' branch
]); // Result: "main data - modified"

Global

Like Branch, but operates on or creates a global branch that persists across forge() calls and instances.

// First call
df.forge('initial', [{ Global: ['sharedState', [{ Append: ' first' }]]}]);

// Second call (same or different instance)
df.forge('something else', [
    { From: 'sharedState' } // Retrieves 'initial first'
]);

Return

Exits the current branch and returns control to the outer (calling) branch. If called from the main branch, it exits the entire forge() execution.

• Without arguments: Returns the current branch's data to the outer branch (respecting the outer branch's mode).
• With argument: Returns the argument value to the outer branch (respecting the outer branch's mode).

df.forge('outer', [
    { Branch: ['inner', [
        { Import: 'inner value' },
        { Return: 'explicit return' } // Returns 'explicit return'
    ]]}
]); // Result: 'explicit return'

From

Imports data from the specified branch into the current branch (respecting current mode). Does nothing if the source branch doesn't exist or is empty.

df.forge('main', [
    { Branch: ['source', [{Import: 'source data'}]] },
    { Append: ' - ' },
    { From: 'source' }
]); // Result: "main - source data"

Alias: ImportFrom, ImportFromBranch

To

Exports the current branch's data to the specified local branch (respecting the current branch's mode). Initializes the target branch if it doesn't exist. Does not switch the current branch.

df.forge('export this', [
    { To: 'targetBranch' },
    // 'targetBranch' now contains 'export this'
    // Current branch remains 'main'
    { From: 'targetBranch' }
]); // Result: "export this"

Alias: ExportTo, ExportToBranch

ToGlobal

Like To, but exports to a specified global branch.

df.forge('export global', [{ ToGlobal: 'sharedTarget' }]);

Alias: ExportToGlobal

CloneTo

Performs a deep clone of the current branch's data and replaces the data in the target branch with the clone. Initializes the target branch if needed.

df.forge({ a: 1 }, [
    { CloneTo: 'cloneTarget' },
    // 'cloneTarget' now has a distinct copy of { a: 1 }
]);

Delete

Deletes the specified local or global branch. Cannot delete reserved branches (like main). Switches to main if the current branch is deleted.

df.forge(null, [
    { Branch: ['temp', [{ Import: 'data' }]] },
    { Delete: 'temp' }
    // 'temp' branch no longer exists
]);

Exit

Immediately stops the entire forge() execution, returning the current data from the branch where Exit was called.

df.forge('start', [
    { Append: ' step1' },
    "Exit",
    { Append: ' step2' } // This is skipped
]); // Result: "start step1"

ExitIfEmpty

Calls Exit if the current branch data is considered empty/lacks value (LacksValue(data)).

df.forge('', ["ExitIfEmpty", { Append: ' not empty' }]); // Result: ''
df.forge('data', ["ExitIfEmpty", { Append: ' not empty' }]); // Result: 'data not empty'

If

Conditionally executes a command block based on evaluating SeeIf conditions against the current data. Conditions can be nested.

df.forge("test value", [
    { If: [ // Conditions array
        'IsString', 'And', 'HasValue', 'And', { LengthIsGreaterThan: 5 }
      ],
      // Optional branch name for commands
      'conditionalBranch',
      // Commands to run if true
      [
        { Append: " - condition was true!" }
      ]
    }
]); // Result: "test value - condition was true!"

Data Conversion Commands

ConvertToArray

Wraps the current data value in an array. Optionally at a specific index.

df.forge("value", [{ ConvertToArray: 0 }]); // Result: ["value"]
df.forge("value", [{ ConvertToArray: 2 }]); // Result: [undefined, undefined, "value"]

ConvertFromArray

Extracts an element from the current array data at the specified index (default 0).

df.forge(["a", "b"], [{ ConvertFromArray: 1 }]); // Result: "b"

ConvertToObject

Creates an object with a single specified key, using the current data as the value.

df.forge("value", [{ ConvertToObject: "newKey" }]); // Result: { newKey: "value" }

Aliases: ToKey, ConvertToObjectWithKey

ConvertFromObject

Extracts the value associated with the specified key from the current object data.

df.forge({ id: 123, name: "Test" }, [{ ConvertFromObject: "name" }]); // Result: "Test"

Alias: FromKey

ConvertToJSON

Serializes the current data (object/array) into a JSON string.

df.forge({ a: 1 }, ["ConvertToJSON"]); // Result: '{"a":1}'

ConvertFromJSON

Parses the current data (JSON string) into a JavaScript object/array.

df.forge('{"a":1}', ["ConvertFromJSON"]); // Result: { a: 1 }

ConvertToString

Converts the current data to its string representation.

df.forge(123, ["ConvertToString"]); // Result: "123"

ConvertToNumber

Converts the current data (string) to a number.

df.forge("42.5", [{"ConvertToNumber": null}]); // Result: 42.5

Handlebars Templating

Dataforge provides a rich Handlebars templating engine, including dynamic protocol handlers for advanced content generation (e.g., {{file:path/to/file.ext}}).

For detailed documentation on all Handlebars features, including template commands (ApplyHandlebars, ToHandlebar, etc.) and the Handlebar Protocol System, please see the dedicated Handlebars Sub-Module README.

Data Manipulation Commands

FromRef

Uses Doh.parse_reference to extract a value from the current data using a dot-notation path.

df.forge({ a: { b: { c: 123 }}}, [{ FromRef: "a.b.c" }]); // Result: 123

Alias: ImportFromRef

MeldDeep

Performs a deep merge (Doh.meld_deep) of the argument object into the current branch's data object.

df.forge({ a: { b: 1 }}, [{ MeldDeep: { a: { c: 2 }}}]);
// Result: { a: { b: 1, c: 2 }}

MeldDeepFrom

Performs a deep merge of the data from a specified local branch into the current branch's data.

df.forge({ a: 1 }, [
    { Branch: ['source', [{ Import: { b: 2 } }]] },
    { MeldDeepFrom: 'source' }
]); // Result: { a: 1, b: 2 }

MeldDeepFromGlobal

Performs a deep merge of the data from a specified global branch into the current branch's data.

df.forge({ a: 1 }, [
    { Global: ['globalSource', [{ Import: { b: 2 } }]] },
    // In a separate forge call or later in the same one:
    { MeldDeepFromGlobal: 'globalSource' }
]); // Result: { a: 1, b: 2 }

Each

Iterates over the current data (if array or object) and executes a sub-pipeline for each item. The result of the sub-pipeline replaces the original item/value.

// Array
df.forge([1, 2], [{ Each: [[{ IncrementNumber: null }]] }]);
// Result: [2, 3]

// Object
df.forge({ a: 1, b: 2 }, [{ Each: [[{ IncrementNumber: null }]] }]);
// Result: { a: 2, b: 3 }

String Operation Commands

(These commands operate on the current branch data if it's a string)

• Trim: Removes leading/trailing whitespace.
• LTrim: Removes leading whitespace.
• RTrim: Removes trailing whitespace.
• ToTitleCase: Converts to Title Case.
• ToUpperCase: Converts to UPPERCASE.
• ToLowerCase: Converts to lowercase.
• ToCamelCase: Converts to camelCase.
• ToSnakeCase: Converts to snake_case.
• ToKebabCase: Converts to kebab-case.
• ToPascalCase: Converts to PascalCase.

df.forge("  some string  ", ["Trim", "ToTitleCase"]); // Result: "Some String"

Number Operation Commands

(These commands operate on the current branch data if it's a number)

• RoundNumber: Rounds to nearest integer.
• FloorNumber: Rounds down.
• CeilNumber: Rounds up.
• TruncateNumber: Removes decimal part.
• IncrementNumber: Adds 1.
• DecrementNumber: Subtracts 1.

df.forge(5.7, ["FloorNumber", "IncrementNumber"]); // Result: 6

Sanitization & Escaping Commands

These commands clean or modify strings to make them safe for specific contexts.

• SanitizeInput: General-purpose sanitization (removes control chars, zero-width chars, etc.).
• SanitizeAlphaNumeric: Keeps only letters and numbers.
• SanitizeNumber: Keeps only numbers.
• SanitizeEmail: Removes characters invalid in email addresses.
• SanitizePhone: Removes characters invalid in phone numbers.
• SanitizeURL: Removes characters invalid in URLs.
• SanitizePath: Removes characters invalid in file paths.
• SanitizeFilename: Removes characters invalid in filenames.
• SanitizeUsername: Alias for SanitizeAlphaNumeric.
• SanitizePassword: Removes characters invalid in typical passwords.
• SanitizeToken: Removes characters invalid in typical tokens.
• SanitizeCode, SanitizeHTML, SanitizeSQL, SanitizeJSON, SanitizeXML, SanitizeCSS, SanitizeJS, SanitizeMarkdown, SanitizeYAML: Remove characters generally invalid for the respective formats.
• EscapeHTML: Escapes <, >, &, ", ' for safe HTML display.
• EscapeJSON: Escapes characters problematic within JSON strings.
• StripHTML: Removes HTML tags.
• RemoveColorCodes: Removes ANSI terminal color codes.

df.forge("<script>alert('bad')</script>", ["StripHTML", "EscapeHTML"]);
// Result: "alert('bad')"

Asynchronous Commands (AsyncDataforge only)

These commands perform I/O and require using an AsyncDataforge instance and await.

Fetch

Fetches data from a URL using axios (Node.js) or Doh.ajaxPromise (Browser). Uses current data as URL if no argument provided.

let result = await adf.forge(null, [{ Fetch: "https://example.com/api/data" }]);

ImportFromURL

Fetches data using Doh.ajaxPromise (browser-focused, forces HTTP).

let result = await adf.forge(null, [{ ImportFromURL: "/api/data.json" }]);

Post

Sends the current branch data as a POST request body to the specified URL.

let postData = { id: 1, value: "test" };
let result = await adf.forge(postData, [{ Post: "/api/submit" }]);

ForgeOnServer

Sends the current data and an array of commands to a server-side endpoint (/dataforge/forge) for remote execution.

let result = await adf.forge('filename.txt', [
    { ForgeOnServer: ["FromFile"] } // Ask server to read file
]);

YAML Commands (YAML_dataforge sub-module)

ConvertToYAML

Serializes the current object/array data to a YAML string.

df.forge({ a: 1, b: [2, 3] }, ["ConvertToYAML"]);
// Result: "a: 1\nb:\n  - 2\n  - 3\n"

ConvertFromYAML

Parses the current YAML string data into a JavaScript object/array.

df.forge("a: 1\nb: [2, 3]", ["ConvertFromYAML"]);
// Result: { a: 1, b: [2, 3] }

File System Commands (nodejs_fs_dataforge sub-module) [Node.js Only]

These commands interact with the local file system and only work in a Node.js environment. They work with both Dataforge (sync) and AsyncDataforge (async).

• ChangeDir: Changes the current working directory for subsequent file operations within the forge instance. [{ ChangeDir: "path/to/dir" }]
• FromFile: Reads content from a file path (provided as argument or from current data). [{ FromFile: "file.txt" }]
• ToFile: Writes the current data to a file path. [{ ToFile: "output.txt" }]
• CopyFile: Copies a file. [{ CopyFile: ["source.txt", "dest.txt"] }]
• CopyFolder: Recursively copies a folder. [{ CopyFolder: ["src_dir", "dest_dir"] }]
• FromFolder: Reads directory contents (returns array of filenames/subdirs). [{ FromFolder: "./dir" }]
• FromFolderToList: Reads contents of multiple files in a folder into an object keyed by filename. [{ FromFolderToList: "./data_files" }]
• FromListToFolder: Writes an object (keyed by filename) to multiple files in a directory. [{ FromListToFolder: "./output_dir" }]
• FromStringToPathToGlobal: Sanitizes the current data string into a path-safe string and stores it in a global branch. [{ FromStringToPathToGlobal: "globalBranchName" }]
