The `object` Pattern: Base of Doh Instances

Objects

The object pattern is the base pattern or root pattern that all other Doh Patterns implicitly inherit from. It provides the functionality required for object instance creation (AsyncNew() as standard, or New() for synchronous-only cases) and management, including inheritance resolution, lifecycle phase management, and the automatic building of child objects (sub-object-building).

This guide covers:

How object instances are created from ideas using the object pattern as a base.
The core features provided by the object base pattern.
Integration with the object lifecycle and phase engine.
How the sub-object-builder system is enabled by the object pattern.
Understanding parent-child relationships in constructed object instances.

`object` Pattern in Context

The object pattern sits at the intersection of several key Doh systems:

Pattern System: object is the root pattern that all other patterns ultimately extend
Inheritance System: object provides the basic inheritance mechanisms
Object Lifecycle: object establishes the phase execution system
Sub-Object-Builder: object implements the auto-building functionality

This integration creates a foundation for Doh's component architecture.

From Ideas to Objects

The Creation Process

In Doh, objects are created from "ideas," which are plain JavaScript object literals. This transformation occurs through AsyncNew(), which is the standard and recommended approach. It enables async phases in the construction lifecycle for all objects and their children:

// Define an idea
let buttonIdea = {
    text: 'Click Me',
    onClick: function() {
        console.log('Button clicked!');
    }
};

// Standard approach: Create a Doh object using AsyncNew()
let buttonObject = await AsyncNew('object', buttonIdea);

// AsyncNew() enables async phases for all objects and children
// Works with both synchronous and asynchronous patterns

This process involves:

Resolving the inheritance chain (in this case, just the 'object' pattern)
Melding properties from the pattern and idea using MOC rules
Executing phase methods in sequence (primarily object_phase and builder_phase)
Returning the fully constructed object

Internal Structure

After construction, a Doh object has internal properties:

inherits: An array listing all patterns in the inheritance chain
inherited: An object containing references to each inherited pattern
moc: The MOC definition controlling property behavior
machine: A function to advance the object through its lifecycle phases
object_phase: Doh's 'init' method
builder_phase: represents this object's phase as an sub-object-builder of children objects

// Internal structure (simplified)
buttonObject = {
    // User-defined properties from the idea
    text: 'Click Me',
    onClick: function() { console.log('Button clicked!'); },

    // Internal properties (normally not enumerable)
    inherits: ['object'],
    inherited: {
        object: { /* reference to object pattern */ },
        idea: { /* reference to original idea */ }
    },
    moc: { /* melded MOC definitions */ },
    machine: function(phase) { /* phase control function */ }
    object_phase: function() { /* melded method executor */ }
    builder_phase: function() { /* melded method executor */ }
}

Core Features of the Object Pattern

1. MOC Definition

The object pattern establishes the basic Melded Object Composition (MOC) structure that governs how properties are composed:

moc: {
    object_phase: 'phase',
    builder_phase: 'phase'
}

This definition specifies that object_phase and builder_phase should use the 'phase' melding type—a special method melding behavior for lifecycle phases.

2. Phase Engine

The object pattern implements the core object lifecycle phase execution engine through its machine function, which:

Tracks which phases have been completed
Executes phases in the correct order
Ensures each phase runs only once
Can advance an object to any specified phase

// Advancing an object to a specific phase
myObject.machine('html_phase');

3. Object Phase

The object_phase is the initial setup phase for all Doh objects:

object_phase: function() {
    // Handle static properties
    for (let prop_name in this.moc) {
        if (this.moc[prop_name] === 'STATIC') {
            // Connect to pattern statics
            for (pattern in this.inherited) {
                if (NotUndefined(this.inherited[pattern][prop_name])) {
                    Doh.mimic(this, prop_name, this.inherited[pattern], prop_name);
                    break;
                }
            }
        }
    }
}

Immediate reads after writes

When using Doh.mimic inside object construction or phases, mirrored values update on the microtask queue. If you set a value and need to read the synchronized counterpart immediately (common in tests), flush first:

await Doh.microtask();

See /docs/core/data-binding#timing-and-microtasks.

Asynchronous Object Phase:

When using AsyncNew(), the object_phase can be asynchronous for patterns that need to perform async initialization:

// Pattern for a database-connected component
Pattern('DatabaseComponent', {
    async object_phase() {
        // Initialize database connection asynchronously
        this.connection = await this.connectToDatabase();

        // Load initial data
        this.userData = await this.connection.query('SELECT * FROM users WHERE active = 1');

        // Set up caching
        this.cache = new Map();
        this.userData.forEach(user => this.cache.set(user.id, user));

        console.log(`DatabaseComponent initialized with ${this.userData.length} active users`);

        // Return values get merged onto this object
        return {
            ready: true,
            userCount: this.userData.length,
            lastInit: new Date()
        };
    },

    async connectToDatabase() {
        // Simulate async database connection
        await new Promise(resolve => setTimeout(resolve, 100));
        return { query: async (sql) => [{ id: 1, name: 'John' }, { id: 2, name: 'Jane' }] };
    }
});

// Must use AsyncNew for patterns with async phases
const dbComponent = await AsyncNew('DatabaseComponent');
console.log(dbComponent.ready); // true
console.log(dbComponent.userCount); // 2

This phase handles essential object setup, including:

Setting up static property connections
Preparing the object for the builder phase
Async initialization like database connections, API calls, or file loading

Because of how phases work, patterns can all have their own 'object_phase' and all the different methods will be stitched together, making it a proper behavioral init path.

4. Builder Phase

The builder_phase is responsible for automated child object construction, integrating tightly with the Sub-Object-Builder system:

builder_phase: function() {
    // Collect all sub-object-buildable properties into this.built
    Doh.collect_buildable_ideas(this, this.moc, this, '');

    // Build all child objects
    if (this.built) {
        this.machine_built = function(phase) {
            // Implementation that builds child objects
        };

        this.machine_built(this.machine_built_to);
    }
}

This phase is crucial for:

Identifying and collecting sub-object-buildable properties
Establishing parent-child relationships
Setting up builder chain navigation helpers
Constructing child objects

Sub-Object-Building Integration

A key feature enabled by the object pattern is its integrated sub-object-building system, which automatically constructs child objects from property definitions.

How Sub-Object-Building Works

During the builder_phase, Doh scans the object for properties with a pattern attribute
These properties are collected in the built object
Each property is instantiated using New() (or AsyncNew() when the parent uses AsyncNew())
The original property is replaced with the fully constructed Doh object
When AsyncNew() is used for the parent, children can also use async phases in their construction lifecycle

// Before builder_phase
myComponent = {
    header: { pattern: 'html', tag: 'header' }
};

// After builder_phase
myComponent = {
    header: /* Fully built Doh object */
};

Defining Sub-Object-Buildable Properties

Properties should be defined in the idea object or pattern definition (before the builder_phase runs):

// Best practice: Define sub-object-buildable properties in the idea
// Use AsyncNew() as standard - enables async phases for all objects and children
let pageObject = await AsyncNew('object', {
    header: {
        pattern: 'html',
        tag: 'header',
        html: 'Page Title'
    },
    content: {
        pattern: 'html',
        tag: 'main',
        html: 'Page content goes here'
    }
});

Parent-Child Relationships

The object pattern establishes a parent-child relationship system:

Builder Reference: Each auto-built object gets a builder property pointing to its parent

// Parent object with child objects
// Use AsyncNew() as standard - enables async phases for all objects and children
let form = await AsyncNew('object', {
    submitButton: {
        pattern: 'Button',
        text: 'Submit',

        // Child object can access parent methods
        onClick: function() {
            this.builder.submitForm();
        }
    },

    // Parent method
    submitForm: function() {
        console.log('Form submitted!');
    }
});

Object Inheritance

The inheritance system in Doh is flexible, allowing for multiple ways to specify inheritance relationships.

Flexible Inheritance Specification

Doh's inheritance system accepts the inherits property in multiple formats:

String Format: For inheriting from a single pattern
Array Format: For inheriting from multiple patterns
Object Format: For complex inheritance rules with conditions

This flexibility appears throughout the system:

// PATTERN DEFINITION: Multiple ways to specify inheritance

// 1. Single inheritance as second argument
Pattern('ButtonPattern', 'UIComponent', {
    // Button-specific properties
});

// 2. Multiple inheritance as array in second argument
Pattern('DropdownButton', ['Button', 'Dropdown'], {
    // Combined functionality
});

// 3. Complex inheritance through inherits property
Pattern('AdvancedComponent', {
    inherits: {
        BaseComponent: true,           // Hard inheritance
        OptionalComponent: false,      // Soft inheritance
        ConditionalComponent: {        // Conditional inheritance
            DependencyComponent: true
        }
    },
    // Component properties
});

// OBJECT CREATION: Similarly flexible inheritance
// Use AsyncNew() as standard - enables async phases for all objects and children

// 1. Direct inheritance through pattern name
let button = await AsyncNew('ButtonPattern', {
    label: 'Click Me'
});

// 2. Multiple inheritance as first argument
let specialButton = await AsyncNew(['Button', 'Draggable'], {
    label: 'Drag Me'
});

// 3. Inheritance through inherits property in idea
let customObject = await AsyncNew('object', {
    inherits: ['BasePattern', 'MixinPattern'],
    // Custom properties
});

// 4. Combining approaches
let complexComponent = await AsyncNew(['BaseComponent', 'UIComponent'], {
    inherits: {
        'SpecialFeature': true,
        'OptionalFeature': false
    },
    // Additional properties
});

Convenience of the Inheritance System

The inheritance system is designed to be flexible and convenient, allowing you to:

Mix in functionality: Combine behaviors from multiple patterns
Apply conditional features: Include patterns only when needed
Create ad-hoc compositions: Assemble functionality without creating named patterns

// Ad-hoc composition example
// Use AsyncNew() as standard - enables async phases for all objects and children
let specialButton = await AsyncNew(['Draggable', 'Resizable', 'Button'], {
    label: 'Special Button',
});

Inheritance Resolution Order

When multiple patterns are inherited, Doh resolves effective order by first expanding all branches of the inheritance tree, then flattening to a list that respects prerequisites and explicit ordering. Keep in mind:

Declared prerequisites and dependency relationships provide the primary ordering. Patterns listed later only affect order if not constrained by dependencies
The idea object is applied after inherited patterns
Properties with a MOC definition combine according to their melder type (e.g., Method, Array, Object). If a property's moc type is set to 'Override', or if it has no melder defined, it is replaced by the most specific later application (often the idea). This makes 'Override' the explicit way to enforce replacement behavior and prevent melding. See the MOC documentation for complete melding rules.
If two sources remain unordered by the dependency graph, a deterministic tie-breaker applies and the finally applied rule wins. Do not rely on this for design—declare prerequisites instead

This inheritance system is central to Doh's pattern-based composition, enabling clean, reusable, and flexible code structures.

Best Practices

Explicit Inheritance: When creating patterns, explicitly inherit from 'object' or another pattern.
MOC Definitions: Always define MOC types for properties that need special handling.
Phase Methods: Place initialization code in the appropriate phase methods.
Sub-Object-Building: Define child objects in the idea or pattern definition, not in phase methods.
Parent-Child Relationships: Use the builder chain navigation methods to maintain loose coupling.
