Sub-Object-Builder: Automatic Hierarchical Components

The Sub-Object-Builder is enabled by the base object pattern, that helps you create hierarchies of nested objects in Doh using simple property definitions. It automatically builds child object instances from your declarations, making it easier to create and manage complex component structures without manual instantiation.

This guide covers:

• How the Sub-Object-Builder relates to the Object Instantiation Lifecycle.
• Defining properties that trigger automatic child object creation.
• How nested object hierarchies are built.
• Using method hooks (related to MOC) for initialization.
• Managing parent-child relationships.

Relation to Object Lifecycle

Understanding Doh's object instantiation lifecycle is essential to effectively using the sub-object-builder system.

Construction Flow Overview

When you create a Doh object using New(), the object goes through several phases:

1. Composition Phase: Patterns and ideas are combined.
2. object_phase: Basic object setup and initialization.
3. builder_phase: This is where the Sub-Object-Builder system runs, automatically constructing child objects.
4. Additional Custom Phases: Any custom phases defined in patterns.

Crucially, properties intended for auto-building must be defined before the builder_phase executes.

Defining Buildable Properties

The recommended approach is to define buildable properties directly in the idea object literal passed to New() or within the Pattern definition itself.

// PREFERRED: Define properties in the idea object literal
let myObject = New('my_pattern', {
  // Direct properties that will be auto-built
  header: {
    pattern: 'html', // The 'pattern' key signals auto-building
    tag: 'header'
  },
  content: {
    pattern: 'html',
    tag: 'main'
  }
});

// GOOD: Define properties in the pattern definition
Pattern('my_pattern', {
  header: {
    pattern: 'html',
    tag: 'header'
  },
  footer: {
    pattern: 'html',
    tag: 'footer'
  }
});

Using the object_phase to define buildable properties should be reserved for cases where the structure is dynamic and cannot be determined beforehand.

Pattern('my_pattern', {
  object_phase: function() {
    // LESS PREFERRED: Only use for dynamic properties
    if (this.config.dynamicLayout) {
      this.dynamicSection = { pattern: 'html', tag: 'section' };
    }
  }
});

The builder_phase (provided by the base object pattern) then finds and processes these definitions:

// The standard builder_phase logic
builder_phase: function() {
  // 1. Collect properties containing a 'pattern' key
  Doh.collect_buildable_ideas(this, this.moc, this, '');

  // 2. Build child objects using New() if any were found
  if (this.built) {
    this.machine_built(this.machine_built_to); // Instantiates items in this.built
  }
}

Phase Execution Order & Hooks

Remember the lifecycle phase execution order:

1. object_phase
2. builder_phase
3. Custom phases

Each phase supports pre_ and post_ hooks, allowing fine-grained control. See Method Hooks below.

How Sub-Object-Building Works

Identifying Buildable Properties

A property is identified as buildable and processed by the Sub-Object-Builder if:

1. It is an object literal.
2. It has a property named pattern whose value is a string (the name of the Pattern to instantiate).

// This property will be auto-built
header: {
  pattern: 'html', // <<< Required key
  tag: 'header'
}

// This will NOT be auto-built (no 'pattern' key)
footer: {
  tag: 'footer'
}

Direct Properties vs. Collections

Doh strongly encourages using named, direct properties for defining child objects, as this is what the Sub-Object-Builder primarily looks for.

// PREFERRED: Direct properties
Pattern('GoodPattern', {
  header: { pattern: 'html', tag: 'header' },
  navigation: { pattern: 'html', tag: 'nav' },
  content: { pattern: 'html', tag: 'main' }
});

While Doh does provide a children array for object relationships, direct properties are favored for auto-building.

The Building Process

During the builder_phase, the system iterates through properties identified as buildable:

1. It calls New() using the property's value (the idea object containing the pattern key and other properties) as the idea argument and passes down a target phase. The target phase is determined by the parent's machine_built_to property (or defaults to 'final'). See Coordinating Child Lifecycles below.
2. The original property on the parent object is replaced with the newly created child object instance (which has only been machined up to the target phase).
3. The original idea used to construct the child is preserved internally on the child at childInstance.inherited.idea.
4. A builder property is added to the child, linking it to the parent.

// Before builder_phase runs on parent
myObject.header = { pattern: 'html', tag: 'header', machine_built_to: 'object_phase' };
myObject.content = { pattern: 'html', tag: 'main' }; // Will build to 'final' (default)

// After builder_phase runs on parent
myObject.header = /* Instance of 'html', machined only to 'object_phase' */;
myObject.header.builder = myObject;
myObject.content = /* Instance of 'html', machined to 'final' */;
myObject.content.builder = myObject;

Nested Hierarchies

The Sub-Object-Builder handles nested definitions recursively. When a child object is built, its own builder_phase runs, potentially building its children.

// Define a complex nested structure
let page = New('object', {
  body: {             // Level 1
    pattern: 'html',
    tag: 'body',
    header: {         // Level 2
      pattern: 'html',
      tag: 'header',
      title: {        // Level 3
        pattern: 'html',
        tag: 'h1',
        html: 'Welcome'
      }
    },
    content: {        // Level 2
      pattern: 'html',
      tag: 'main'
    }
  }
});

// After building, you have a complete hierarchy:
// page.body
// page.body.header
// page.body.header.title
// page.body.content

Method Hooks and Initialization

The Melded Object Composition (MOC) system provides hooks that are useful in the context of sub-object-building.

pre_ and post_ Hooks for Phases

You can define pre_builder_phase and post_builder_phase methods (and hooks for any phase) to run code immediately before or after the main phase logic.

• pre_builder_phase: The ideal place to dynamically define properties that need to be auto-built. This hook runs before the builder collects buildable properties.
• post_builder_phase: Runs after all child objects for the current object have been built. Useful for setting up relationships between siblings or between parent and children.

Pattern('PhasedBuilderPattern', {
  moc: {
    object_phase: 'phase',
    builder_phase: 'phase'
    // custom_phase: 'phase' // example
  },

  // Define dynamic children just before building starts
  pre_builder_phase: function() {
    if (this.config.needsWidget) {
      this.widget = { pattern: 'Widget', config: this.config.widgetConf };
    }
  },

  // Setup relationships after children are built
  post_builder_phase: function() {
    if (this.widget && this.mainContent) {
      // Example: Let widget know about main content area
      this.widget.contentArea = this.mainContent;
      console.log('Widget and Main Content linked.');
    }
  }
});

Inheritance and Hook Execution Order

As described in the MOC documentation, when inheriting multiple patterns, hooks execute in a specific order relative to the main phase methods:

1. All pre_ hooks (inheritance order: base to derived)
2. All main phase methods (inheritance order: base to derived)
3. All post_ hooks (inheritance order: base to derived)

Parent-Child Relationships

Auto-built objects automatically establish parent-child relationships:

• builder Property: Each auto-built child object receives a builder property that points directly to its parent (the object it was defined within).
• Builder Chain Navigation: Child objects can access properties and methods from their parent (or ancestors) using:
  • this.builder_property('propertyName'): Searches up the builder chain for the first ancestor with the property.
  • this.builder_method('methodName'): Searches up the builder chain for the first ancestor with the method and returns a bound function.

Pattern('ParentPattern', {
  parentData: 'Some Value',
  parentMethod: function() { console.log('Parent method called!'); },

  // Child property that will be auto-built
  child: {
    pattern: 'ChildPattern'
  }
});

Pattern('ChildPattern', {
  accessParent: function() {
    // Direct access via builder property
    console.log(this.builder.parentData); // -> Some Value
  }
});

const instance = New('ParentPattern');
instance.child.accessParent();

Coordinating Child Lifecycles (Advanced)

It is possible to influence the lifecycle phases child objects are initialized to during the automatic build process using the parent object's machine_built_to property. This is an advanced mechanism primarily used to coordinate the initialization of UI controls after they have registered but before they are fully rendered.

For a detailed explanation of this mechanism and its primary use case within the control registration system, please see the Control Registration System documentation in the html pattern guide.

Best Practices

1. Define Properties Statically Where Possible

Define buildable properties directly in the idea object (passed to New()) or within the Pattern definition, rather than dynamically in phases, unless necessary.

// BEST: In idea
let obj = New('object', { child: { pattern: 'X' } });

// GOOD: In pattern
Pattern('Parent', { child: { pattern: 'X' } });

// OK (Only if dynamic): In pre_builder_phase
Pattern('DynamicParent', {
  pre_builder_phase: function() { this.child = { pattern: 'X' }; }
});

// BAD: In builder_phase or later (too late for auto-build)
Pattern('LateParent', {
  builder_phase: function() { /* ... */ this.child = { pattern: 'X' }; }
});

2. Prefer Direct Properties Over Collections

Use named, direct properties for children. This leverages the Sub-Object-Builder directly and makes the structure clearer.

// PREFERRED
Pattern('Layout', {
  header: { pattern: 'Header' },
  footer: { pattern: 'Footer' }
});

// DISCOURAGED for auto-building
Pattern('Layout', {
  object_phase: function() {
    this.children = [
      { pattern: 'Header' },
      { pattern: 'Footer' }
    ];
  }
});

3. Use Hooks Appropriately

• Use pre_builder_phase to define dynamic child properties.
• Use post_builder_phase to configure relationships between children or between parent and children after they are built.

4. Keep Nesting Understandable

While the system supports deep nesting, overly nested structures can become difficult to manage. Consider flattening hierarchies where appropriate by composing smaller, focused patterns.

Key Takeaways

1. The Sub-Object-Builder automatically instantiates properties containing a pattern key during the builder_phase.
2. Define buildable properties statically in ideas/Patterns when possible; use pre_builder_phase for dynamic definitions.
3. Direct properties are preferred for auto-building.
4. Parent-child relationships are automatically established (builder, builder_property, builder_method).
5. Use post_builder_phase for setup that requires children to exist.
